Documentation RM-310 C / RM-310 CT / RM-310 C Plug and Play / RM-310 CT Plug and Play
RDN 10001104 26 14.07.2020
Parameter block D0-D8 “Δp-controls“
Parameter D0 “Δp-controls“
Parameters D1-D8 can be faded in or out with parameter D0. Parameter D0 is factory-set to 1. The "Δp
control" is also active. It Δp control is not active, cleaning is set to the "continuous" mode.
D0 =
Text in display, line 3
Meaning
0
0 inactive
Parameters D1-D8 are faded out (invisible)
1
1 active
Parameters D1-D8 are faded in (visible)
Parameter D1 “Δp Cleaning mode“
The operating mode of the differential pressure-dependent cleaning can be set with parameter D1.
D1 =
Text in display, line 3
Meaning
0
0 DP measure
The control only serves as differential pressure measuring device
with all Δp alarm switch points.
1
1 DP cont.clean.
Cleaning works continuously independent from the differential pres-
sure, with the parametrised control times (see parameters E1, E3,
E5 and E9). The Δp alarm switch points set are active.
2
2 DP stop clean.
The dedusting works in start-stop mode.
If the differential pressure reaches the start value set with parameter
D5 cleaning is activated until the differential pressure falls below the
value D5 - D6 (Δp start value minus Δp hysteresis value). The valve
number selected last is stored to enable cleaning to continue with the
subsequent valve when starting again.
3
3 DP cl.stop end
The dedusting works in the start-stop mode with circulation ending.
If the differential pressure reaches the start value set with parameter
D5, the valve number is stored and cleaning is activated until the dif-
ferential pressure falls below the value D5 - D6 (Δp start value minus
Δp hysteresis value) and the stored valve number is reached. (At
least 1 complete circulation is always carried out.)
4
4 DP-Stop end
Cleaning works in stop-end mode.
If the differential pressure reaches the Δp start value set by parame-
ter D5 cleaning remains active until the differential pressure drops
below the D5 - D6 (Δp start value minus Δp hysteresis value) and the
last valve has been operated.
Parameter D2 “Sensor source”
The source of the differential pressure measurement is set with parameter D2.
D2 =
Text in display, line 3
Meaning
0
0 RM-XXX Sensor1
Δp measurement via sensor 1 of the RM-310 CT
1
1 RM-XXX =4-20mA
Δp measurement via the current input
I1 of the RM-310 C
2
2 RM-VXX Sensor
Δp measurement via the sensor of the I/O module RM-V6/X
1
or
RM-V8
2
/ RM-V16
2
with the address No.1
3
3 RM-VXX =4-20mA
Δp measurement via the current input of the I/O module RM-V8
2
or
RM-V16
2
with the address No.1
1
only types RM-310 C Plug and Play and RM-310 CT Plug and Play
2
only types RM-310 C and RM-310 CT
