Documentation RM-310 C / RM-310 CT / RM-310 C Plug and Play / RM-310 CT Plug and Play
RDN 10001104 34 14.07.2020
Display Meaning
Ext.cleaning on
Row 1
The input "Cleaning on" carries 1-signal at factory setting.
* The function of the inputs can be individually set via parameter group F0-
F8. See appendix 7 "Input and output signal parametrisation,
special
parameters" on this.
Cont. cleaning on
Row 1
Control released and continuous cleaning on.
F-clean.in 5 min
Row 1
Start of active forced cleaning in 5 minutes
Forced cleaning on
Row 1
Cleaning is activated after the forced cleaning time has
elapsed.
Cleaning on
Row 1
Cleaning has been activated because the rising differential
pressure of the filter has reached the value „
DP Start
“.
Cleaning off
Row 1
Cleaning has been deactivated because the dropping differen-
tial pressure of the filter has reached the value „DP Start“
minus „DP Hyster.“.
With the indicator flashing when the release of cleaning has
been requested but not granted (see parameter
Fn = 10/30 or Gn = 6/38).
The following is displayed in rows 3 and 4 in all operating
modes except in downtime:
Filter valv.no.###
Ctrl.## Valv.no.###
Row 3
Row 4
The cleaning valve with the filter number ### is active.
Location:
Control number
##
/ Control valve number
###
DP-Filter #### Pa
DP-contr. deactive
Row 2
Row 2
#### effective measured differential pressure of the filter or
parameter D0 is set to the value 0.
2
Row 2 The controller is in the 2nd downtime cycle.
