9
Remove and discard hex shipping bolts on left and right sides of grill body (1).
Hex bolts were used to ensure interior welds were supported during shipping.
Carefully open the lid on your grill and locate the RTD wires secured to the temperature sensor.
Feed the RTD wires through the grill body.
Step 5
Prepare for Side Shelf and Pull Bar Assembly
With assistance, line up the side shelf with
controller (8) against the exterior of grill body
(1).
Follow bolt assembly order.
Use hardware D.
Tip: Begin with the bolt from the interior of the
grill barrel using the bolt assembly order. This will
give you easier assembly access with a Phillips
head screwdriver for a more secure build.
Hand tighten until all screws are in place.
Step 6
Install Side Shelf
Top of Grill
Top of Grill
