Rectifier MCSU-4 - Page 19

Installation, Operation and Technical Manual Rectifier Technologies
158-1872-01 15 19-Feb-14
Figure 4.5. MUIB Fuse Function and Specification
Fuse
Function
Specification
F4
+15VDC
F500mA, Glass, M20x5
F5
-15VDC
F500mA, Glass, M20x5
F8
Ground
T2A, HRC, M20x5
F46
-V System
T2A, HRC, M20x5
F49
-V Battery
T2A, HRC, M20x5
F53
+V System
T2A, HRC, M20x5
F63
+V Battery
T2A, HRC, M20x5
F68
+V LVDS
T2A, HRC, M20x5
F69
-V LVDS
T2A, HRC, M20x5
