The RSM reports the following values to the user:
o Average Rectifier % Output Power
o Number of Rectifiers On-Line
o Number of Rectifiers Sleeping
SMR Sleep Mode Enable.
Sleep Mode
Off
SMR Sleep Mode Minimum rectifiers that must be online.
Sleep Min SMR
4
Max power of each SMR module. For RT12, rectifiers, this should
be set to 2400 as each module is rated for 2.4kW
SMR Power Max
2400
SMR Sleep Mode rectifier rotation value (in Days).
Sleep Rotation
5 Days
SMR Sleep Mode report number of rectifiers sleeping
Sleeping SMRs
3
SMR Sleep Mode report number of rectifiers online
Sleep SMR Online
5
SMR Sleep Mode report Average Rectifier % Output Power
Sleep Av Power
80 %
6.8 Battery Parameter Menu Screens
All information pertaining to the batteries is accessed by momentarily pressing the Batt
button on the front panel. To return to the MCSU-4 “home” menu at any time, momentarily
press the Batt button.
As for the other menus, in general a programmable parameter can be incremented or
decremented by use of the INC and DEC buttons respectively. If this is attempted when a
monitored parameter is being displayed (i.e. not a programmable operating parameter),
then the message “Not Adjustable” will be displayed.
The following screens will appear in turn when the INC button is pressed:
Battery 1 Current;
Battery 1
12A
