Installation, Operation and Technical Manual Rectifier Technologies
158-1872-01 55 19-Feb-14
Number of SMRs in the system. This number must be
entered correctly. Otherwise the display will show that some
SMRs are not responding (number too big) or will not be
monitored (number too small).
Selection of the interface hardware being used to connect
the MCSU-4 to the power system. Depending on the
system (48V, 110V, 220V) and the software used, the
options can vary from MUIB to MUIB5
Number of battery banks in the system. When MUIB2 is
used up to 4 batteries can be monitored, with other interface
types maximum number is 2.
Battery current transducer full scale rating. E.g. if a Hall
effect transducer has 200A/4V rating, enter 200 in the
screen.
MCSU-4 Access code address; this can be a number up to
7 digits long
Date format. The format of the date can be modified to
either DD/MM/YYYY, MM/DD/YYYY or YYYY/MM/DD.
Clock set; used to set the date and time of the MCSU-4
clock. Note DD/MM/YYYY 24 hour clock. While setting the
time clock is stopped. Seconds are not programmable.
Date 25/12/2002
Time 21:58:35
Alarm Report; this can be toggled On and OFF. If ON and
use of a modem is declared, the system will dial the first
telephone number (Phone 1) in the screens below when an
alarm occurs. If Phone 1 does not answer, it will try Phone
2; if 2 does not answer then it will dial Phone 3. If 3 does not
answer it will begin again at Phone1
Daily Report; this can be toggled from ON to OFF; When
ON, unit will send routine report at the time programmed in
next menu. If use of modem is declared unit will follow
connection procedure as for Alarm Report
Time of daily report. This menu is available only when Daily
Report is switched ON.
