Equalisation Voltage. This sets the maximum voltage
reached during equalisation of the batteries.
System Equalise
59.5V
Equalisation not initialised by voltage level.
Volts Start Eq
Off
Equalisation initialised by voltage level V reached during
battery discharge.
Volts Start Eq
On
Equalisation is initialised when the battery voltage falls to
this level.
Volts Eq Trigger
46.0V
Equalisation is not initialised by the discharge A/H method.
Q Start Eq
Off
Equalisation is initialised based on charge supplied to the
load by the batteries (measured in Ampere-Hours).
Q Start Eq
On
Equalisation is initialised when the charge out of the
batteries is greater than the level set in this screen.
Q Loss Trigger
10Ah
Equalisation is ended based on the level of battery charging
current set in this screen.
EQ End Current
25A
If Equalisation is to end independently of charging current,
reduce the value of current in this screen to less than 5% of
the A/H rating of the batteries (programmed in earlier
screen) and the number will then be replaced by “Off”.
EQ End Current
Off
Equalisation can be terminated after the time set in this
screen. If termination is based only on the A/H discharge
method, set this number to its highest value (48 Hr).
EQ Duration
20 hours
If no equalisation occurs due to battery discharges for a
period longer than the time set in this screen, an
equalisation cycle will be initiated automatically. Can be
switched off by setting number of weeks to zero.
EQ Period
12 Weeks
Equalisation can be ended manually by pressing ENTER
when this screen appears. This screen is only obtained if
the system is in Equalisation mode.
Manual Stop EQ
Press ENTER
When ENTER is pressed, the system reverts to Float mode
and the window changes to that shown, ready for a manual
equalisation start. This screen is only obtained if the system
is in Float mode.
Manual Start EQ
Press ENTER
End of equalisation section.
