5 - DRAWINGS AND TECHNICAL FEATURES
TECHNICAL CHARACTERISTICS PRIMULA - ORCHIDEA AIR
Nominal output power 9.5 kw (8170 kcal/h)
Minimal output power 2.4 kw (2064 kcal/h)
Eciency at Max 91.7%
Eciency at Min 94.1%
Temperature of exhaust smoke at Max 180 °C
Temperature of exhaust smoke at Min 100 °C
Particulate /OGC / Nox (13%O
2
) 22 mg/Nm3 - 6 mg/Nm3 - 121 mg/Nm3
CO at 13% O
2
at Min and at Max 0.025 – 0.014%
CO
2
at Min and at Max 5.7% - 8.7%
Recommended draught at Max*** power 0.10 mbar - 10 Pa***
Minimum draft allowed at minimum power 0.00 mbar - 0 Pa
Smoke mass 7.7 g/sec
Hopper capacity 44 litres
Type of pellet fuel Pellet diameter 6-8 mm and size 5/30 mm
Pellet hourly consumption Min ~ 0.6 kg/h* - Max ~ 2.0 kg/h*
Autonomy At min ~ 48 h* - At max ~ 15 h*
Heatable volume m
3
204/40 – 233/35 – 272/30 **
Combustion air inlet Ø 50 mm
Smoke outlet Ø 80 mm
Air intlet 80 cm
2
Rated electrical power (EN 60335-1) 80 W (Max 420 W)
Supply voltage and frequency 230 Volt / 50 Hz
Net weight 160 kg
Weight with packaging 170 kg
Distance from ammable material (back) 50 mm
Distance from ammable material (side) 100 mm
* Data that may vary depending on the type of pellets used
** Volume that can be heated, according to the power requirement per m
3
(respectively 40-35-30 Kcal/h per m
3
)
***Value recommended by the manufacturer (non-binding) for optimal product operation
Tested according to EN 14785 in accordance with European regulation for Construction Products (EU 305/2011).
