5 - DRAWINGS AND TECHNICAL FEATURES
TECHNICAL CHARACTERISTICS DALIA AIR
Nominal output power 6.0 kw (5160 kcal/h)
Minimal output power 2.1 kw (1720 kcal/h)
Eciency at Max 92.8%
Eciency at Min 94.0%
Temperature of exhaust smoke at Max 160 °C
Temperature of exhaust smoke at Min 100 °C
Particulate /OGC / Nox (13%O
2
) 27 mg/Nm3 - 7 mg/Nm3 - 112 mg/Nm3
CO at 13% O
2
at Min and at Max 0.059 – 0.013%
CO
2
at Min and at Max 4.1% - 8.0%
Recommended draught at Max*** power 0.10 mbar - 10 Pa***
Minimum draft allowed at minimum power 0.00 mbar - 0 Pa
Smoke mass 6.0 g/sec
Hopper capacity 20 litres
Type of pellet fuel Pellet diameter 6-8 mm and size 5/30 mm
Pellet hourly consumption Min ~ 0.5 kg/h* - Max ~ 1.45 kg/h*
Autonomy At min ~ 25 h* - At max ~ 8 h*
Heatable volume m
3
129/40 – 147/35 – 172/30 **
Combustion air inlet Ø 50 mm
Smoke outlet Ø 80 mm
Air intlet 80 cm
2
Rated electrical power (EN 60335-1) 80 W (Max 320 W)
Supply voltage and frequency 230 Volt / 50 Hz
Net weight 120 kg
Weight with packaging 130 kg
Distance from ammable material (back) 50 mm
Distance from ammable material (side) 50 mm
* Data that may vary depending on the type of pellets used
** Volume that can be heated, according to the power requirement per m
3
(respectively 40-35-30 Kcal/h per m
3
)
***Value recommended by the manufacturer (non-binding) for optimal product operation
Tested according to EN 14785 in accordance with European regulation for Construction Products (EU 305/2011).
