Charge the GoBlock | 15
Charge Directly From a Vehicle Alternator
Connect directly to your vehicles alternator via an extension cable (not included) to the Auxiliary
Anderson™ Input on the back of the GoBlock. Use a suitable adaptor if the power output connector
on you vehicle is not an Anderson™ connector.
Visit the REDARC website for detailed instructions on how to run a direct wire from your start
battery to charge via the Auxiliary Anderson Input.
The extension cable positive wire must be fused to 60A. Refer to the 'Cable Sizing' table to select
an appropriate cable gauge for your installation.
NOTICE
REDARC recommends only using genuine Anderson™ connectors manufactured by
Anderson Power Products
®
for GoBlock installations. Counterfeit or generic connectors may
result in a poor quality connection.
Charging from a vehicle alternator via an Anderson™ cable.
CABLE SIZING
Purchase cable length and gauge to suit your individual installation. Cable length refers to the total
cable length of the install (positive + negative cable length). Always choose a wire cross sectional
area equal to or greater than what is specified below. The selected cable must be capable of
carrying a minimum of 60A.
Cable Install Length
Recommended Wire
Cross Section
Closest Equivalent
(BAE, B&S, AWG)
1–5m 3'–16' ≥13.56mm² 6
5–9m 16'–30' ≥20.28mm² 4
