Redarc RS Series User Manual

6
1 INTRODUCTION
Model: R-12-1500RS-NA
Input
Characteristics
Max. Rated Input Current 157A
Voltage 12V DC
Over-Voltage Protection 16.5±0.3V DC
Under-Voltage Protection 10.5±0.3V DC
Voltage Range 10.5~16.5V DC
No Load Current ≤1.8A@12V DC
Power Saving Mode <0.1A@12V DC
Output
Characteristics
Continuous Output Power 1500W (VA) (±3%)
Maximum Output Power (1 min) >1500~1730W (VA) (100%~115%)
Surge Power (<3 sec) <2650W (VA)
Frequency 50/60Hz±0.5% (Dip Switch Selectable)
Output Voltage
100/110/115/120V AC (±5%)
(Dip Switch Selectable)
Efficiency Max 91%
Short-Circuit Protection 1 Sec Shutdown, restart to recover
Output Waveform
(1)
Pure Sine Wave (THD<5% @ Normal Load)
Signal and
Control
Remote Controller Panel Input REMOTE-RS (optional)
LED Indicator Red/Orange/Green LED
Dry Contact Terminal By a relay
Remote Control Terminal 6-port Green terminal (for inverter ON/OFF)
Protection
Input Protection
(2)
Over/Under Voltage, Reverse Polarity
(Internal Fuse)
AC Output Protection Short-Circuit, Overload
Others
Over/Under Temperature Protection (by Heat
sink Temperature 176°F (80°C)/–4°F (–20°C))
Environment
Operating Temp.
–4~104°F — Derates to 140°F)
(–20~40°C — Derates to 60°C)
Storage Temp. –22~158°F (–30~70°C)
Storage Temp. and Humidity 10~95% RH
Safety and
EMC
Safety Standards UL 458, C22.2 No. 107.1
EMC Standards
(3)
FCC Class B, CAN ICES-003 (B)/NMB-003(B)
Weight 9.7 lb (4.4kg)
Cooling Temperature and Load Controlled cooling Fan
Dimensions (W×H×D) 9.8"×3.3"×16.6" (248×83×421mm)
(1) Normal load condition: Vin=12.5V/25V/50V, Vo=100/110/115/120 V AC 80% load (PF=1.0)
(2) Reverse polarity connection can blow the internal fuse and may damage the inverter permanently.
(3) Refer to page 26 for compliance information.
