Redarc The Manager30 - REMOTE DRILL TEMPLATE

37
4 REMOTE DRILL TEMPLATE
7.32" (186 mm)
⌀0.17"
(4.4 mm)
⌀1.95" (49.5 mm)
2.91" (74 mm)
1.95" (49.5 mm)
4.41" (112 mm) 5.68" (144 mm)
PHOTOCOPY OR PRINT THIS
PAGE AT 100% SCALE
Before drilling holes, ensure
that this template is printed at
the correct size.
Cut/drill the red line.
0
mm
10 20 30 40 50
in
0 1 2
