1 INTRODUCTION
7.283" (185 mm)
16.890" (429 mm)
17.520" (445 mm)
15.906" (404 mm)
3.228
"
(82
mm)
3.110" (79 mm)
FIGURE 1.4.1: Main Unit Dimensions
1.063"
(27 mm)
2.914" (74 mm)
7.323" (186 mm)
0.827" (21 mm)
1.412" (29 mm)
FIGURE 1.4.2: Remote Monitor Dimensions
