FCC Compliance Statement! The radio included with your vehicle complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful Interference, and (2) This device must accept any interference received,
including interference that may cause undesired operations.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
TX
FCC ID: 2A2UNRTX4C00
IC: 24025-RTX4C00
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not
cause interference, and (2) this device must accept any interference, including interference that may cause undesired operations of this device.
WARNING: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this
equipment.
WARNING: While operating the Radio, a separation distance of at least 20 centimeters must be maintained between the radiating antenna and the body
of the user or nearby persons in order to meet the FCC RF exposure guidelines.
AFHDS (automatic frequency hopping digital system)
AFHDS was developed for Radio control models and offers active and passive anti-jamming capabilities, low power consumption and high receiver
sensitivity.
This radio system works in the frequency range of 2.405 to 2.475GHz. This band has been divided into 141 independent channels. Each radio system uses
16 different channels and 142 different types of hopping algorithm. By using various switch-on times, hopping scheme, and channel frequencies, the
system is less likely to lose transmission.
Each transmitter has a unique ID. When binding with a receiver, the receiver saves that unique ID and can accept only data from that unique transmitter.
This avoids picking another transmitter signal and dramatically increases interference immunity and safety.
WARNING: Even with the AFHDS 2A-BS technology, if the radio system is not used in accordance with this manual, it can still fail and cause
serious injury. Be sure to read and understand this entire manual, as well as the manual that came with all other RC components you are
using.
ESC/RECEIVER SPECS.
Number of Channels 3
Compatible Models 1:18 Crawler
RF 2.4GHz ISM
2.4GHz Protocol 2A-BS
Distance ≥ 300m（Ground Distance w/o Interference）
Input Power 2S LiPo
BEC Output 5V/1A
Data Interface PWM
Cont. / Peak Current 10A/40A
Applicable Motors 180 Brushed Motor
Temperature Range -10deg. Celsius ~ +60deg. Celsius
Humidity Range 20% ~ 95%
Weight 9.8g
Dimensions 38*25*13mm
Dimensions 38*25*13mm
Certifications CE, FCC ID: 2A2UNR3A00
TRANSMITTER SPECS.
Number of Channels 4
Use Surface use only
RF 2.4GHz ISM
Maximum Power <20dBm (e.i.r.p.)（ EU）
2.4GHz Protocol 2A-BS
Distance >300m (Ground Distance w/o Interference)
Channel Resolution 1024
Input Power (4x)1.5AA batteries
Low Voltage Alarm <4.2V
Antenna Built-in
Temperature Range -10deg. Celsius ~ +60deg. Celsius
Humidity Range 20% ~ 95%
Dimensions 160*193*97mm
Weight 220g
Certifications CE，FCC ID： N4ZG4P00
Specifications
TM
3
R3C Radio/ESC Guide
