BushChook – Installation and Operation Manual
Page 2 of 48
Issue date: 19/12/2023. Version 1.1
Safety instructions
Indicates additional information, emphasized contents or tips that may be helpful.
Caution, risk of electric shock.
Do not touch live parts until 10 minutes after disconnection from the power sources.
The wiring diagrams and installation instructions are given as a guide only and compliance to appropriate standards is
the responsibility of the installer. Relevant standards are listed below:
Installation and safety requirements for photovoltaic (PV) arrays
-alone power systems-Design
Structural design actions
-Safety of battery systems for use with power conversion equipment
The BushChook must only be installed by suitably qualified personnel who have read and are familiar with its operation
and hazards.
The battery provided with this system must only be charged by the Deye inverter or the V2G (vehicle to grid) charger
supplied by RedEarth. Do not attempt to charge the batteries with any other charging device or connect any devices
directly to the DC battery bus unless approved by RedEarth.
In the event of a fire evacuate the area and call emergency services. A dry agent fire extinguisher should be readily
available and used. DO NOT use water. MSDS document is provided with the system and can be found at
www.redearth.energy
Do not use a damaged battery. Batteries should only be disposed of at an appropriate recycling centre. Please
contact RedEarth for advice.
A battery can present a risk of electrical shock and high short-circuit current. The following precautions should be
observed when working on batteries:
• Remove watches, rings, and other metal objects.
• Use tools with insulated handles.
Disconnect charging source prior to connecting or disconnecting battery terminals.
In our efforts towards constant product enhancement, this document is subject to change at any time. Please visit
www.redearth.energy and download the appropriate and latest version manual.
Lifting hazard
The BushChook is heavy. Observe proper lifting techniques. To reduce the weight the Troppo batteries can be removed.
Fire
The BushChook uses RedEarth's Troppo battery. This is a lithium-iron-phosphate based battery (LFP). It is the safest lithium
chemistry. However, in the case of a fire the following steps should be taken. A dry agent fire extinguisher should be readily
available and used. DO NOT use water. Evacuate the area and call emergency services. To x i c g a s m a y be produced if the
battery catches fire.
Note:
The SDS document for the Troppo Battery can be found at www.redearth.energy
WARNING:
Working on the inside of the BushChook system is restricted to qualified
personnel. RedEarth recommend installation by licensed electricians only.
