Redexim 7117 - Page 33

ITEM
PART NUMBER DESCRIPTION
REMARKS
QUA
1 802.060.400 Bolt M6 x 40 - ISO 4014 Quantity for one element 1
2 830.100.100 Self Lock Nut M10 - ISO 10511 Quantity for one element 7
3 804.100.450 Bolt M10 x 45 - ISO 4017 Quantity for one element 2
4 804.120.500 Bolt M12 x 50 - ISO 4017 Quantity for one element 1
5 872.035.150 Circlip D=35 - DIN 472 Quantity for one element 4
6 713.150.110 Bearing 6202-LLU Quantity for one element 10
7 4001675 Tine holder bolt M10x35 Quantity for one element 3
8 448.610.830 Bearing support Empty Quantity for one element 2
9 464.083.300 Element strip Quantity for one element 2
10 448.401.320 Tine holder Empty Quantity for one element 1
11 416.151.100 Support Axle Short Quantity for one element 1
12 416.151.310 Support Axle Long Quantity for one element 1
13 402.150.150 Inner bush Quantity for one element 2
14 412.150.050 Distance washer Quantity for one element 4
15 404.120.130 Distance bush tine holder Quantity for one element 2
16 802.100.600 Bolt M10 x 60 - ISO 4014 Quantity for one element 1
17 830.140.140 Self Lock Nut M14 - ISO 10511 Quantity for one element 2
18 830.120.120 Self Lock Nut M12 - ISO 10511 Quantity for one element 3
19 713.300.130 Bearing 6006 LLU Quantity for one element 2
20 872.055.200 Circlip D=55 - DIN 472 Quantity for one element 1
21 448.401.200 Big End Empty Quantity for one element 1
22 412.270.030 Inner bush Quantity for one element 1
23 402.300.180 Distance bush Quantity for one element 2
24 468.072.180 Connecting rod 12
25 2890052 Stop Quantity for one element 1
26 802.100.400 Bolt M10 x 40 - ISO 4014 Quantity for one element 4
27 2381404 Connecting rod middle 4
28 2381402 Connecting rod center 4
29 830.080.080 Self Lock Nut M8 - ISO 10511 Quantity for one element 1
30 802.080.450 Bolt M8 x 45 - ISO 4014 Quantity for one element 1
31 872.047.180 Circlip D=47 - DIN 472 Quantity for one element 2
32 713.250.120 Bearing 6005-LLU Quantity for one element 2
33 872.028.130 Circlip D=28 - DIN 472 Quantity for one element 1
34 476.321.830 Tube for draw rod Quantity for one element 1
35 448.640.820 Draw rod head with hole Quantity for one element 1
36 448.640.960 Draw rod head with stud Quantity for one element 1
37 426.161.720 Draw rod Quantity for one element 1
38 864.140.012 Shim S=1 Quantity for one element 2
39 446.280.200 Rubber stop Quantity for one element 1
40 406.180.200 Distance bush Quantity for one element 1
41 442.180.300 Bearing bush Quantity for one element 1
42 761.160.030 Seal Quantity for one element 1
43 576.241.320 Compression spring Quantity for one element 1
44 406.120.120 Distance bush Ø25/Ø12 L=12 Quantity for one element 1
45 406.100.120 Distance bush Ø25/Ø10 L=12 Quantity for one element 1
46 404.100.040 Distance bush Ø55/Ø32/Ø10 L=4.25 Quantity for one element 1
47 404.100.050 Distance bush Ø55/Ø32/Ø10 L=5.2 Quantity for one element 1
48 404.120.050 Dust washer Ø55/Ø32/Ø12 L=5.2 Quantity for one element 1
49 404.120.040 Dust washer Ø55/Ø32/Ø12 L=4.25 Quantity for one element 1
50 490.323.552 Drawrod complete
Redexim Code Page Verti-Drain 7117 04 1621
111pr013-PP04
