Description Page
Foreword 2
Guarantee conditions 2
Registration card 2
Safety instruction
3
1.0 Technical specification 5
2.0 First setup, lifting machine from pallet 6
3.0 General controls 7
4.0 PTO 8
4.1 PTO length 8
4.2 Use of PTO 9
4.3 Slip clutch information and maintenance 9
5.0 Working depth adjustment 10
6.0 Tine angle adjustment 10
7.0 Groundspeed 11
8.0 Starting procedures 12
9.0 General usage of Verti-Drain 13
10.0 Transport of Verti-Drain 13
11.0 Uncoupling of the Verti-Drain 13
12.0 Problem analysis 14
13.0 Maintenance 15
14.0 EU-Declaration 15
15.0 Technical information 16
15.1 Torque settings 17
15.2 The crankshaft 17
15.2.1 Replacing the transmission oil seal 17
15.2.2 Replacing of a crank and crank bearing 18
15.2.3 Removing the crankshaft tension 18
15.3 Alignment of an element 18
15.4 Assembly of the crown wheel and pignon 19
16.0 Options, tines 21
16.0.1 Solid tines 21
16.0.2 Hollow tines 22
16.1 Options, Core Collector 22
16.2 Options, Turf hold down kit 24
16.2 Options, Windrow kit 25
