Redexim 7117 - Page 35

ITEM
PART NUMBER DESCRIPTION
REMARKS
QUA
1 2281502 Protection plate 2
2 804.100.200 Bolt M10 x 20 - ISO 4017 4
3 2604527 Distance bush 16
4 406.460.120 Distance bush 4
5 2465010 Splined shaft long 4
6 2465012 Splined shaft short 6
7 2447102 Crank plate nut side 10
8 2447100 Crank plate big end side 8
9 4221078 Lock Washer MB/AW Ø40 20
10 4165400 M40x1.5 KM8 20
11 834.270.180 Self lock nut M27 10
12 2490105 Big End Pin 8
13 713.450.160 Bearing 6009-LLU 10
Redexim Code Page Verti-Drain 7117 05 1621
111pr013-PP05
