Redexim 7117 - Page 37

ITEM
PART NUMBER DESCRIPTION
REMARKS
QUA
1 462.403.800 Support 1
2 892.400.020 Plastic Stop 40x40 1
3 523.100.570 Linch pin - 9 1/2mm 7
4 2251100 Top linkage strip 2
5 2251102 Top link support strip 2
6 2611518 Distance bush 1
7 521.191.120 3-Point Pin 1
8 2490881 Bottom 3-Point Pin 2
9 802.161.300 Bolt M16 x 130 - ISO 4014 1
10 830.160.160 Self Lock Nut M16 - ISO 10511 7
11 804.140.500 Bolt M14 x 50 - ISO 4017 4
12 830.140.140 Self Lock Nut M14 - ISO 10511 4
13 830.120.120 Self Lock Nut M12 - ISO 10511 2
14 802.200.550 Bolt M20 x 55 - ISO 4017 4
15 830.080.080 Self Lock Nut M8 - ISO 10511 4
16 2281506 Support plate central bar 2
17 2381400 Central draw bar VD7117 1
18 426.161.020 Bolt assembly Central Bar 2
19 2611527 Distance plate 3mm 2
20 2611528 Distance plate 2.5mm 2
21 446.300.700 Cover for lever 1
22 468.032.120 Handle for angle adjustment 1
23 2282186
Support bolt assembly central bar
7117/7316
1
24 2691018 U-Bolt M8, for tube 50 2
25 402.130.100 Distance bush Ø12.5/Ø40 L=10 4
26 2900100 Frame VD 7117 1
27 2479102 Clamp 2
28 814.120.550 Bolt M12 x 55 - DIN 912 4
29 521.161.050 Pin 4
Redexim Code Page Verti-Drain 7117 06 1621
