ITEM
PART NUMBER DESCRIPTION
REMARKS
QUA
1 830.160.160 Self Lock Nut M16 - ISO 10511 16
2 864.160.030 Washer M16 - ISO 7089 12
3 802.160.700 Bolt M16 x 70 - ISO 4014 4
4 468.123.700 Main Rear Roller support 4
5 464.153.820 Second rear roller support 2
6 804.080.200 Bolt M8 x 20 - ISO 4017 8
7 830.080.080 Self Lock Nut M8 - ISO 10511 8
8 864.080.030 Washer M8 - ISO 7089 12
9 523.030.750 R-Clip Round 3, DIN 11024 2
10 521.160.510 Lock pin rear roller 2
11 802.160.550 Bolt M16 x 55 - ISO 4014 8
12 880.060.100 Grease nipple M6 DIN 71412A 4
13 742.250.360 Bearing UCFL 205 4
14 2281510 Rear roller scraper support 7117 2
15 2281512 Rear roller scraper 7117 1
16 2343800 Front roller 7117 2
17 404.160.160 Pivot bush 8
18 468.062.162 Scraper support right 1
19 468.062.160 Scraper support left 1
20 468.089.170 Scraper 1
21 2381200 Front roller support 7117 2
22 2282096 Spindle nut bracket 2
23 2282098 Spindle nut TR18x4 2
24 2281520 Bolt Assembly 2
25 804.080.300 Bolt M8 x 30 - ISO 4017 4
26 830.100.100 Self Lock Nut M10 - ISO 10511 4
27 802.100.450 Bolt M10 x 45 - ISO 4014 4
28 866.080.020 Spring Washer M8 - DIN 127 4
29 406.180.170 Distance bush Ø18/Ø10.2 L=16.5 4
30 2281738 Height indicator 2
31 2611534 Bush 2
32 2692101 Spindle 2
33 2282108 Spindle head 2
34 878.050.220 Roll Pin 5 x 22 - ISO 8752 2
Redexim Code Page Verti-Drain 7117 07 1621
111pr013-PP07
