Redexim 7117 - Page 41

ITEM
PART NUMBER DESCRIPTION
REMARKS
QUA
1 804.080.200 Bolt M8 x 20 - ISO 4017 12
2 2471220 Top plate gearbox 1
3 2401203 Casing gearbox 1
4 4561000 Tap 1/2" 2
5 2401204 Rear part gearbox 1
6 820.210.180 Level / fill glass 1
7 4067008 Breather gearbox 1
8 2471241 Shield 1
9 1991400 Gear shifter 1
10 2779976 Fork 1
11 2469200 Lever with pin 1
12 4752009 Seeger RS9 1
13 4420170 O-ring D13.1x2.62 1
14 2894039 Plastic washer 19x34x1.5 1
15 878.040.200 Roll Pin 4 x 20 - ISO 8752 1
Use liquid silicon paste to seal parts
Use oil 80W90 3 liter
1441100-34 Gearbox complete
Redexim Code Page Verti-Drain 7117 08 1621
111pr013-PP08
