Redexim 7117 - Page 43

PART NUMBER DESCRIPTION
REMARKS
QUA
1 872.072.250 Circlip D=72 - DIN 472 2
2 870.035.160 Circlip d=35 - DIN 471 3
3 872.080.250 Circlip D=80 - DIN 472 1
4 2462005 Axle 1
5 4165400 M40x1.5 KM8 2
6 4221078 Lock Washer MB/AW Ø40 2
7 4135000 Nut 1
8 2460400 Input shaft 1
9 2611208 Distance bush 1
10 2611200 Distance bush 1
11 432.200.892 Gearwheel Z=19 1
12 432.200.720 Gearwheel Z=15 1
13 432.200.810 Gearwheel Z=17 1
14 2504421 Gearwheel Z=17 1
15 2504467 Gearwheel Z=21 1
16 432.320.890 Gearwheel Z=19 1
17 2611212 Distance bush 2
18 2661256 Washer 1
19 711.350.170 Bearing 6207 2
20 4810470 Bearing 32208 2
21 4816750 Bearing 6305 2
22 4809420 Bearing 30209 2
23 2611108 Distance bush 1
24 2471100 Bearing support flange 2
25 2462003 Pignon shaft 1
26 4317430 Cotter Pin 3.2 x 56 - DIN 94 1
27 884.100.350 Key 10x8x35 - DIN 6885 1
28 2611110 Mounting bush 1
29 2611109 Mounting bush with thread 1
30 814.100.400 Bolt M10 x 40 - DIN 912 1
31 4307024 Shims 55x45
Set of shims: (2x) 0.1, 0.2, 0.3, 0.5, 1 and 2
mm
1
32 814.060.200 Bolt M6 x 20 - DIN 912 12
33 4755035 Seeger SW35 1
34 4423350 O-ring Ø88.57x2.62 2
35 4408880 Oil Seal 60x75x8 2
36 4406420 Oil seal 35x72x10 1
37 2490105 Big End Pin 2
38 432.200.970 Crown wheel Z23 1
39 432.450.820 Pignon wheel Z19 1
Redexim Code Page Verti-Drain 7117 09 1621
111pr013-PP09
