ITEM
PART NUMBER DESCRIPTION
REMARKS
QUA
1 152140207 Outer tube 1
2 151014006 Outer tube yoke 1
3 190000014 Outer roll pin 1
4 180014130 Cross and 4x circlip kit 2
5 141024430 Complete collar yoke 1
6 1422400307430 Complete guard Cut to correct length 1
7 190000012 Inner roll pin 1
8 151004007 Inner tube yoke 1
9 153140107 Inner tube 1
10 180014022 Spring 8
11 180015020 Bush 1
12 180014019 Lining ring 2
13 151014018 Hub 1
14 180014020 Pressure plate 1
15 165000502 Bolt and Nut Retighten every 40 hours 1
16 151014017 Flanged yoke 1
17 165000501 Bolt and nut 8
400510 Complete PTO
ALWAYS deburr parts when cut
MEASURE correct length of PTO first
MAINTAIN slipclutch every month
NEVER USE PTO over 30 degrees angle
SLIPCLUTCH always on machine side
Redexim Code Page Verti-Drain 7117 PTO 10 1612
111pr013-PP11 (PTO)
