Redexim 7117 - Page 49

ITEM
PART NUMBER DESCRIPTION
REMARKS
QUA
1 468.089.000 Windrow plate 2
2 464.106.350 Windrow support 2
3 406.170.150 Distance bush 2
4 406.130.150 Distance bush 2
5 802.120.650 Bolt M12 x 65 - ISO 4014 4
6 804.120.450 Bolt M12 x 45 - ISO 4017 2
7 804.160.450 Bolt M16 x 45 - ISO 4017 2
8 864.160.031 Large washer M16 - DIN 9021 2
9 830.120.120 Self Lock Nut M12 - ISO 10511 2
10 830.160.160 Self Lock Nut M16 - ISO 10511 2
11 523.030.752 Special R-clip d3 4
12 864.120.030 Washer M12 - ISO 7089 4
13 846.080.241 D-Shackle D8 6
14 406.120.150 Distance bush 4
15 804.080.250 Bolt M8 x 25 - ISO 4017 2
16 846.064.300 Chain, 12 chackles (d=5mm l=0.5m) 3
17 822.080.360 Lifting Eye Nut M8 - DIN 582 4
211.731.010 Windrow kit 7117 complete
Redexim Code Page Verti-drain 7117 Optional Windrow kit 13 1612
111PR013-PP Windrow kit
