Redexim 7117 - Page 51

ITEM
PART NUMBER DESCRIPTION
REMARKS
QUA
1 470.049.202 Frame beam 1
2 468.035.420 Right side plate 1
3 468.035.422 Left side plate 1
4 468.013.100 Blade spring 15
5 804.080.160 Bolt M8 x 16 - ISO 4017 30
6 830.080.080 Self Lock Nut M8 - ISO 10511 43
7 804.080.200 Bolt M8 x 20 - ISO 4017 4
8 404.080.700 Distance bush 4
9 822.100.400 Eye bolt M10 x 40 DIN 444 - LB 4
10 826.100.100 Nut M10 - DIN 934 4
12 830.100.100 Self Lock Nut M10 - ISO 10511 4
12 446.049.201 Rubber strip 1
13 804.080.250 Bolt M8 x 25 - ISO 4017 9
14 864.080.030 Washer M8 - ISO 7089 18
15 404.160.100 Distance bush 4
16 864.160.030 Washer M12 - ISO 7089 4
17 470.053.000 Support arm 2
18 802.160.650 Bolt M12 x 65 - ISO 4014 4
19 523.030.752 Special R-clip d3 4
20 846.080.241 D-Shackle D8 4
21 846.064.300 Chain d=5mm l=0.5m 2
22 822.080.360 Lifting Eye Nut M8 - DIN 582 2
9300080 Core Collector 7117 complete 1
Created with SolidWorks
Redexim Code Pag Verti-Drain 7117 Optional Core Collector 14 1621
