 29 
Key# Part Number Description Q'ty
1 848D4A6500 BLADE ASS’Y 1
2 T4544-11110 • PLATE, upper 1
3 T4544-11120 • PLATE, lower 1
4 848D4A65A0 • BLADE 2
5 T4521-11311 • SPACER 8
6 T4520-11331 • SCREW 5
7 01252-30520 • BOLT 2
8 01252-30525 • BOLT 1
9 T4531-11350 • NUT 6
10 T4543-11410 • PLATE 1
11 848D3066E1 • BRACKET 1
12 T4544-11230 • COVER 1
13 848D306111 GEARCASE COMP. upper 1
14 06004-06001 • BEARING 2
15 04065-02812 • RING 1
16 848D3061B0 • PLATE 1
17 T4543-42320 • BOLT 2
18 848D306121 GEARCASE COMP, botom 1
19 848D3061B0 • PLATE 1
20 T4543-42320 • BOLT 2
21 T4543-21220 GASKET 1
22 848D305111 DRUM 1
23 848D3062A0 GEAR, drive 1
24 T4543-42210 GEAR, driven 1
25 T4543-42100 ROD ASS’Y 2
28 3199-13350 FITTING 1
29 T4543-42410 FELT 1
30 3310-31720 BOLT 4
31 01252-30625 BOLT 3
32 848D3115E2 PIPE, exhaust 1
33 01252-30510 BOLT 1
34 3350-15250 BOLT 6
35 848D4A3300 HANDLE REAR ASS’Y 1
36 T4506-31210 • LEVER, throttle 1
37 T4506-31310 • ARM 1
38 T4506-31412 • LEVER, lock 1
39 T4506-31420 • KNOB 1
40 T4506-31430 • SPRING 1
41 8488P00000 • CABLE COMP 1
42 T4506-52110 • SWITCH 1
43 T4506-52120 • CODE COMP 1
44 3356-33321 • SPRING, throttle 1
45 2630-31950 • SCREW 5
46 2630-33610 • SCREW 1
47 T4506-31511 STOPPER 1
48 848D4A32A1 HANDLE FRONT 1
49 T4506-41110 FRAME 1
50 T4506-41220 HOLDER 2
51 848D4A37A0 SPRING, front 2
Key# Part Number Description Q'ty
52 848D4A37B0 SPRING, rear 2
53 2630-32610 SCREW 2
54 848D4A91F0 LABEL, caution 1
55 T4535-12250 LABEL 1
56 848D3G93A0 MANUAL 1
57 848D4A63A0 BRACKET 1
101 8488U00010 TOOL SET 1
102 T4017-91130 • SOCKET 1
103 3540-91120 • SPANNER 1
104 1030-91340 • DRIVER 1
105 09007-00425 • WRENCH 1
1 848D4B6500 BLADE ASS’Y 1
2 848D4B66A0 • PLATE, upper 1
3 T4543-11120 • PLATE, lower 1
4 848D4B65A0 • BLADE 2
5 T4521-11311 • SPACER 9
6 T4520-11331 • SCREW 6
7 01252-30520 • BOLT 2
8 01252-30525 • BOLT 1
9 T4531-11350 • NUT 7
10 T4543-11410 • PLATE 1
11 848D3066E1 • BRACKET 1
12 848D4B68A0 • COVER 1
64 848D4B91F0 LABEL 1
Fig.2 CUTTING UNIT CHTZ2400 (S/N 40100101 and up)
CHTZ2400-L (S/N 40100101 and up)
CHTZ2400-L
