 31 
Key# Part Number Description Q'ty
1 T1551-12110 CYLINDER 1
2 848F0112B0 GASKET, base 1
3 4820-12130 BOLT TORX M5XL22 T27 4
4 848F0014A2 INSULATOR 1
5 T1551-13121 GASKET, insu 1
6 T1551-13131 GASKET, carb 1
7 T4950-52001 BOLT TORX M5xL20 T27 4
8 T1551-16110 COVER, tr 2
9 T1551-16142 GASKET, tr 2
10 4820-16310 BOLT TORX M4xL10 T27 4
20 848F012110 CRANKCASE-C 1
21 T1551-21141 GASKET, case 1
22 06030-06001 BEARING 2
23 4810-21210 SEAL 1
24 1850-21220 SEAL 1
25 04065-02812 RING 1
26 4820-13180 BOLT TORX M5xL20 T27 3
30 848F0041A1 PISTON 1
31 5910-41210 RING 2
32 1600-41310 PIN 1
33 1260-41320 RING 2
34 T1551-41410 BEARING 1
35 1101-41340 WASHER 2
36 848F014201 CRANKSHAFT-C 1
37 1650-43230 NUT M8xP1.0 1
38 1000-43240 KEY 1
40 848F337111 ROTOR-A 1
41 2841-71120 • PAWL 2
42 2850-71140 • SCREW 2
43 2850-71151 • WASHER 5x10x10 2
44 T1501-71130 • SPRING 2
45 T1551-71200 COIL-A 1
46 4810-72111 • CAP 1
47 1900-72120 • SPRING 1
48 2850-71320 • TUBE 1
49 1260-71261 SPACER 2
50 4820-72150 BOLT TORX M4xL16 T27 2
60 848F018101 CARBURETOR-A 1
61 848F600630 • REBUILD KIT 1
62 T1551-81450 • • BODY-A 1
63 4810-06021 • • GASKET KIT 1
64 1850-81490 • BODY 1
65 1850-81520 • COVER 1
66 1751-81510 • PUMP 1
67 848F0181P0 • JET 1
68 1751-81240 • O-RING 1
69 1751-81130 • RING 1
70 1881-81140 • SWIVEL 1
71 1752-81110 • SCREW 2
72 5500-81120 • BRACKET 1
73 1751-81180 • NUT 1
74 1918-81170 • SCREW 1
75 1850-81530 • SCREW 4
76 5500-81160 • WASHER 1
77 4820-15310 BOLT TORX M5xL50 T27 2
78 1950-86120 CLIP 1
90 848F0115A0 MUFFLER 1
91 4820-15310 BOLT TORX M5xL50 T27 2
92 848F0115C2 GASKET, muff 1
Key# Part Number Description Q'ty
93 T1551-15220 PLATE 1
94 4820-12350 BOLT TORX M5xL10 T27 2
100 848F0131A1 COVER, engine 1
101 848F0131B1 DEFLECTOR 1
102 4820-32120 BOLT TORX 2
110 T1700-51100 SHOE-C 1
111 T1700-51110 • SHOE 2
112 T1700-51220 • SPRING 1
113 1140-51230 WASHER 2
114 1970-51241 WASHER 2
115 1140-51250 SCREW 2
116 848F0151G0 PLATE, clutch 1
117 2850-55211 WASHER 1
120 848F017210 CORD-C 1
121 T2070-73110 SPARK PLUG 1
122 4810-72120 GROMET 1
130 848F017511 RECOIL-A 1
131 5500-75110-02 • NUT 1
132 T1512-75120 • REEL 1
133 T1501-75130 • SPRING 1
134 1850-75151 • SCREW 1
135 T1501-75160 • ROPE 1
136 3330-75421 • KNOB 1
137 4820-32120 BOLT TORX 4
140 848F018310 BODY-A 1
141 T1501-82130 • PLATE, choke 1
142 T1501-82140 • LEVER 1
143 2630-33610 • SCREW 1
144 848F0183F0 ELEMENT 1
145 T1501-82180 SCREEN 1
146 T1501-82200 COVER-A 1
147 5500-82221 • KNOB 1
150 848F018501 TANK-A 1
151 T1501-85120 • PACKING 2
152 T1015-85202 • CAP-A 1
153 4500-85300 • • HOLDER-A 1
154 4500-85220 • • PACKING 1
155 5601-85260 • • FILTER 1
156 4820-85260 • • STOPPER 1
157 848F018530 • PIPE-C 1
158 3302-85400 • FILTER 1
159 2841-31280 • COLLER 1
160 4820-32120 BOLT TORX 3
180 848F0191C0 LABEL, recoil 1
181 T1551-31130 LABEL, cover 1
220 848F028310 BODY-A (OPTION) 1
221 T1512-82130 • PLATE, choke (OPTION) 1
222 T1600-82140 • LEVER (OPTION) 1
223 T1108-82190 • SCREW (OPTION) 1
224 T1513-82120 • PACKING (OPTION) 1
225 T1513-81270 ELEMENT (OPTION) 1
226 848F0283K0 PLATE (OPTION) 1
227 T1513-82200 COVER-A (OPTION) 1
228 T1108-82220 • KNOB (OPTION) 1
Fig.3 ENGINE UNIT HTZ2400/CHTZ2400 (S/N 40100101 and up)
HTZ2400-L/CHTZ2400-L (S/N 40100101 and up)
