Refer
to
Lubrication Interval
Month
ly
Yearly
Each
50
hours
Each
250
hours
Each
500
hours
C
Replace the filter. X X
Replace the hydraulic oil.
10
X X
Do a check of the hydraulic oil level. X
D Lubricate the grease nipple with a grease gun. X X X
E
Replace the engine oil.
11
X X X
Do a check of the engine oil level. X
F Replace the oil filter. X X X X
Always use good quality grease. Always use
recommended oil, refer to Technical data on page
29 .
To lubricate the front wheels
• Remove the dust cap (A). Grease the nipple (B)
with a grease gun until grease comes out from
the top washer.
A
B
C
• Lubricate the joint bearing of the front wheels (C)
with a grease gun until grease comes out.
To lubricate the cutting deck
spindles
1. Set the cutting deck in mow position.
2. Lubricate each cutting deck spindle 2-3 strokes.
Note: Use a grease gun with a rubber hose
when you lubricate the cutting deck spindles.
Troubleshooting
Troubleshooting schedule
If you cannot find a solution to your problems in this
operator's manual, speak to your Husqvarna service
agent.
10
Replace the hydraulic oil and filter for the first time after 1000 hours. Must be done by approved
service agent.
11
Replace engine oil each 50 hours when operating with a heavy load or at high ambient temperatures.
