REMOVING AXIS LOCKING HOLDER
The third bolt is not visible in the image above. As
shown in the sample image, the third bolt located
at the back must also be removed.
The axis locking gear is
fastened to the semi-circular
block retaining ring with
three 6-mm bolts. You can
unscrew these bolts by
turning them counterclockwise
with a wrench.
