PORTS
6-Bar Air Inlet. Connect the
8mm pneumatic hose to the air
compressor.
Ensure that the air is dry and clean.
Otherwise, air-operated pas
including the spindle motor may be
damaged.
Power Buon (On/O). When the buon is
in position (0), the machine is o. When the
buon is in position (1), the machine is on.
Back Panel
1
1
2
2
3
3
8mm x 7.5m Pneumatic Hose – 1 pc
