USER INTERFACE / ATC
On the ATC-Twin Tool page, tools assigned to the magazines are shown. You can add or
remove twin tools on the ATC page.
1
In the image, all tools
are positioned on the
magazine. Tool no.
12 is on the spindle.
The tools assigned on the ATC page are shown on the twin tool page. Since tool no. 12 is on the spindle in the image,
M12 is highlighted in green. All other tools from 1 to 11 that are on the magazine are shown in dark blue.
Twin Tool
