DAILY MAINTENANCE
UTILITY / MAINTENANCE
COLLET MAINTENANCE KIT
1. Brush
2. 17-mm open-end wrench
3. 22-mm open-end wrench
4. Ramrod
Removing the Collet
The collet is loosened by turning an
17-mm open-end wrench and 22-mm
open-end wrench in opposite directions
as shown in the image.
2
21 43
Brush
Use the brush to clean the collet.
1
