WORKPIECE RETAINER
EQUIPMENT
The lower ring is positioned as shown in the
image. The workpiece is placed on the lower ring.
The workpiece and the lower and upper rings are
fastened to each other with screws.
Ensure that there is no di or debris between
the lower and upper rings and then join them
as shown in the image.
1
2
3
