PART LIST
REDZONE
TM
DVS SERIES AIR HANDLER MANUAL
DVS400 DVS600 DVS800 DVS1000 DVS1200
Relay PTRC-1C-24C-T5-X PTRC-1C-24C-T5-X PTRC-1C-24C-T5-X PTRC-1C-24C-T5-X PTRC-1C-24C-T5-X
Transformer PU30va PU30va PU30va PU30va PU30va
Motor RW400ECM-1/3 RW600ECM-1/3 RW800ECM-1/3 RW1000ECM-3/4 RW1200ECM-3/4
Door Switch CARLING-TA20B CARLING-TA20B CARLING-TA20B CARLING-TA20B CARLING-TA20B
Coil BC9061 BC9061 BC9061 BC7923FX BC7923FX
Housing DC1020-600-5 DC1020-600-5 DC1020-600-5 DC1020-800-5 DC1020-800-5
Pump UPS15-58RU UPS15-58RU UPS15-58RU UPS15-58RU UPS15-58RU
Check Valve 96806141 96806141 96806141 96806141 96806141
Flow Valve
Mesurflo Mesurflo Mesurflo Mesurflo Mesurflo
2517- 1.0GPM 2517- 1.5GPM 2517- 2.0GPM 2517- 2.5GPM 2517- 3.0GPM
Control Board ECB 1.0 ECB 1.0 ECB 1.0 ECB 1.0 ECB 1.0
Replacement Parts List
Wiring diagram located on page 16
