DVS SERIES AIR HANDLER MANUAL
LOCATING AND MOUNTING
THE AIR HANDLER
General
The multi-position DVS Series Air Handlers are shipped
requiring only minor modifications to the cabinet.
The appropriate return air opening must be cut out
and the supplied filter rack installed. For instructions
on required modifications and assembly refer to
Figures 3 and 4.
SIDE FILTER
RACK ASSEMBLY
SCREW FILTER RACK
TO SIDE OF CABINET
USING MOUNTING HOLES
CUT SIDE RETURN OPENING
AS REQUIRED
BOTH SIDES
AND BOTTOM KNOCKOUTS
USE EXI STING SCREW HOLE
TO LOCATE FILTER RACK
G
F
DIMENSIONS
ON PREVIOUS PAGE
DIMENSIONS
ON PREVIOUS PAGE
FIGURE 3 Modification of Unit to Accommodate
Side Filter Rack Installation
FIGURE 4 Side Filter Rack Installation
( See Figure 2 for dimensions )
