Reebok SL8.0 - Page 10

ITEM DESCRIPTION QTY.
1 Console 1
2 Upper cable 1
3 Fla
t washer
(ø8*ø19*2T,BLK)
4
4 Screw (M8*P1.25*16L) 4
5 Saddle (3B-21Q+GEL) 1
6 Console tray rear cover 1
7 Screw (M5*16L,BLK) 6
8 Water bottle holder 1
9 Saddle post 1
10 Upper slider cover 1
11 Lower slider cover 1
12 Knob 1
13 Horizontal slider 1
14 Slider fixed bolt 1
15 End cap 2
16 Belt 1
17 Chain cover (R) 1
18 Crank (R) 1
19 Pedal (R) 1
20 Crank cover 2
21 Nut 2
22 Screw 4
23 Pillar (ø9*91.6L) 1
24 Adaptor (9V 1A) 1
25 Nylon nut (M8*7T,13) 3
26 Idler plate 1
27 Idler spring
(ø16*ø2.5(65Mn))
1
28 Flat washer
(ø8*ø22*1T)
1
29 Screw (M8*20L) 1
30 Wave washer
(ø10.2*ø13*0.3T)
1
31 Idler wheel 1
32 Bearing (6000 2ZZ) 2
33 Sleeve (3mm) 1
34 Chain cover right trim
cover
1
35 Screw (ST2.9*10L) 17
36 Nylon nut (M6*5.5T) 4
37 Crank axle 1
38 Hex screw
(M6*P1.0*16L)
4
39 Spring washer
(ø6.1*1.6T)
4
40 Hex screw
(M8*55L*S25L)
1
41 Magnetic system 1
42 Spring 1
43 Pull pin 1
44 Belt pulley (ø260) 1
45 Flat washer
(ø20.3*ø30*0.5T)
1
ITEM DESCRIPTION QTY.
46 Wave washer
(ø20.5*ø30*0.3T)
1
47 Bearing (
6004 2RS) 2
48 Sleeve 1
49 Screw (M8*P1.25*20L) 5
50 Flat washer
(ø8*ø19*2T)
10
51 Screw (M5*12L,BLK) 2
52 Sensor bar fixed seat 1
53 Frame 1
54 Spring washer
(Ø13.5xØ8.5)
9
55 Lower cable 1
56 Hex screw
(M5*P0.8*12L,8)
2
57 Foot tube end cap (L) 2
58 Induction wire 1
59 DC wire 1
60 Wrench with screwdriver
(13.15.17)
1
61 Socket wrench with
screwdriver (13.14)
1
62 Allen Key (6*35*150mml) 1
63 Rear foot tube 1
64 Hex nut (M10,BLK) 2
65 Rubber pad (M10) 4
66 Screw
(M8*P1.25*60L*S20L)
4
67 Foot tube end cap (R) 2
68 Nut 2
69 Bearing (6000) 1
70 Small belt pulley
(ø34*J8)
1
71 Flywheel axle (3/8”-
26*130L ,BLK)
1
72 Bearing (6203 2RS) 1
73 Flywheel
(280*32W*7KG)
1
74 One-way bearing
(ø35*17)
1
75 Bearing (6003 2RS) 1
76 Bearing (6300 2RS) 1
77 Plastic sleeve
(ø10*ø15.8*9mm)
1
78 Flat washer
(ø30*ø34*0.8T)
1
79 Plastic sleeve
(ø10*ø15.8*6mm)
1
80 Hex nut (3/8”-26*3.8T) 3
81 Motor 1
82 C shape clasp
(ø18.5*ø22.5*1T)
2
83 Chain cover left trim
cover
1
84 Chain cover (L) 1
ITEM DESCRIPTION QTY.
85 Screw (ST3.9*50L) 7
86 Crank (L) 1
8
7 Pedal (L) 1
88 Screw (ST2.9*20L) 4
89 Screw (M8*40L*S18L) 2
90 Transport wheel 2
91 Bearing (608 2ZZ) 4
92 Front foot tube 1
93 Hand pulse 2
94 Handlebar grip (L) 1
95 Handlebar 1
96 Handlebar cover 2
97 Hand pulse cover 4
98 Flat washer
(ø5.5*ø12*2T)
2
99 Semicircle washer
(ø8*ø19*2T)
1
100 Handlebar grip (R) 1
101 Console tray front
cover
1
102 Screw (ST2.9*20L) 4
103 Screw (M5*10L(ø9.5) 4
104 Nylon nut (M8*7T) 2
105 Upright post cover 1
106 Hand pulse wire 2
107 Upright post 1
108 End cap 2
109 Spring washer
(ø8.1*2.5T,)
5
P.9
