Reebok ZJET 430 - Exploded Diagram and Parts List

ZJET 430
ASSEMBLY GUIDE
Exploded Diagram
Parts List
NO DescriptionSPEC. Q’ty NO DescriptionSPEC. Q’ty
1Console 166Chain cover (L)1
2Screw M5*4 5L 167Chain cover left trim cover1
3Speed controller 168Bearing 2203 2
4Flat washer
169Frame 1
5Screw M5 870Belt510 J6 1
6Upper induction wire 171Screw M8*P1. 25*55L*S 17 1
7Console tray lower cover172 Nylon nutM8*7T,131
8Screw M7*P 1. 0*30L273 Flat washer
1
9Spring washer 274Magnetic system 1
10 Flat washer 275Belt pulley 289*61
11 Spring washer 81476Screw M6*P 1. 0*16 L4
12 Co nsole tray upper cover177 C shape clasp 2
13 Center shaft lower cover178 Nylon nutM64
14 Center shaft upper cover179 Spring washer 铔 4
15 Upright post 180Crank axle 1
16 ScrewM8*P1.25*16 L6 81 ScrewM8*20L1
17 Upright post small sheath 182Idler whee l1
18 Upright post cover183 Bearing600 01
19 Handlebar grip 284Screw M6*101
20 Fixed handlebar
22.2*2 T*900L 185Idler plate1
21 Hand puls e wire 186Idler spring 1
22 Hand puls e287 Fly whee l axle 3/8"-26*12 6L 1
23 ScrewST2.9*2 0L 688Bearing 6300 1
24 End cap289 6mm Plastic slee ve 10 * 15 .8*6mm 1
25 Center shaft
17 *3 50L(M8)190 Nut3/8"-26*3 .8T, 3
26 Plastic slee ve
17 * 32*15L 291Nut 3/8"-26*7T,2
27 Wave washer
292Chain cover (R)1
28 Lowe r handlebar (R)193 Chain cover right trim cover1
29 Bearing600 3494 Footplate tube (R)1
30 Flat washer
295Footplate (R)1
31 ScrewM8*P1.25*20L2 96 Sensor bar1
32 Moving handlebar upper cover297 1
33 Moving handlebar lowe r cover298 ScrewM5*10 2
34 Wave washer
499Bearing 6004 2
35 ScrewM6*20L410 0Flat washer 1
36 ScrewM8*P1.25*50L4 10 1Wave washer 1
37 Nylon nutM8810 2C shape clasp 1
38 Semicircle washer
6103 Magnetic system spring 1
39 Upper handlebar (L)110 4Speed controller upper wire 1
40 Upper handlebar grip 2105 Upper handlebar (R )1
41 End cap210 6Screw 8
42 ScrewM5*16 13 10 7End cap2
43 ScrewST2.9*2 010108 Screw2
44 Lowe r handlebar (L)3/16"*3 /4 ", 1109 Flat washer
2
45 Bearing600 14110Flat washer
8
46 Slee ve 8.1* 12 *3 8L 2111Screw ST3.9*20L, 8
47 C shape clasp 4112Screw 3/16 "*3/4",8
48 ScrewM8*P1.25*55L2 113Nut M102
49 Flat washer
10 114Flat washer 4
50 Footplate tube (L)1115Screw ST2.9*8L ,48
51 F ootplate upper cover2116Flat washer
1
52 Footplate lowe r cover2117Wave washer
10 .2* 13 *0 .3T, 1
53 Front foot tube 1118Flat washer
1
54 ScrewM8*40L*S12L 4119Lower induction wire 1
55 Transport whee l212 0M51 Toroidal cores1
56 ScrewM6*10 L212 1Speed controller lower wire 1
57 Flat washer
2122 Hex wrench 6mm*30mml*84mml1
58 Foot tube end cap412 3Socket spanner13.14 1
59 Lock shee t3T412 4Water bottle holder 1
60 Adjustable foot padM8412 5Nylon nutM6*5.5T,101
61 Rear foot tube 1126 Footplate knob 1
62 Footplate (L)112 7Fly whee l1
63 Turnplate cross212 8Screw M6*P 1. 0*60L, 1
64 Turnplate212 9Nut M6*4 .5T,10 1
65 Turnplate cover213 0
