Specifications
AC Voltage
Range: 10 to 600V
Accuracy: ±(2.0% rdg + 1V)
Resolution: 0.1V
AC Current
Range: 10 to 200A
Accuracy: ±(2.0% rdg + 1A)
Resolution: 0.1A
General Specifications
Channels: Dual channel, TRMS AC Voltage or Current
Display: Dual LCD
Min/Max: Yes
Datalogging Capabilities: Yes
Real-Time Clock and
Date Stamp: Yes
Selectable Sampling Rate: 1 second to 24 hours
Max Datapoints: 256,000
Auto Shut-off: Yes (after 5 minutes of inactivity)
Low Battery Indicator: Yes
Clamp Jaw Opening: 0.5" (12.7mm)
Power Supply: 4 AAA Batteries or AC Adapter
Battery Life: Sampling Time Dependent
Overvoltage Category: CAT. III 600V
Product Certications: CE
Operating Temperature: 0 to 122°F (0 to 50°C)
Storage Temperature: -4 to 140°F (-20 to 60°C)
Operating Humidity Range: 10 to 75%
Dimensions: 4.5 x 2.5 x 1.3" (114 x 63 x 34mm)
Weight: 8.7oz (248g)
