Reed Instruments R5003 - Meter Description

7
Meter Description
5
4
3
2
1
10
9
12
14
13
11
8
6
7
R5003
1. LCD Display
2. AC Adaptor Jack
3. POWER Button
4. MAX/MIN Button
5. Channel Input Jacks
6. USB Port
7. START/STOP Button
8. Channel Selection Button
9. AC Current Clamp Jaw
10. Jaw Opening Trigger
11. Current Sensor Plug
12. Voltage Module
13. AC Voltage Probes/
Alligator Clips
14. Voltage Sensor Plug
