Accuracy
Notes:
• Measurement performed at the test socket
• Measurements performed after correct open and short calibration
• DUT and test leads must be properly shielded
• Q value is the reciprocal of DF
• Accuracies based within 10% to 100% of full scale of range;
values outside of range should be used as reference only
• “---” means parallel or series measurement mode
Inductance @ Ta = 18 to 28°C (De)
Frequency = 100 Hz/120 Hz
Frequency = 1kHz
Range Resolution Lx Accuracy DF Accuracy Measurement Mode
20.000mH 1µH 1.5% ±10d 1.5% ±50d Series
200.00mH 0.01mH 1.4% ±15d 1.4% ±50d Series
2000.0mH 0.1mH 1.5% ±15d 1.5% ±50d Series
20.000H 1mH 1.6% ±10d 1.6% ±50d ---
200.00H 0.01H 1.3% ±10d 1.3% ±50d Parallel
2000.0H 0.1H 2.0% ±15d 2.0% ±50d Parallel
20.000kH 0.001kH 2.5% ±15d 2.5% ±50d Parallel
Range Resolution Lx Accuracy DF Accuracy Measurement Mode
2000.0µH 0.1µH 1.3% ±10d 1.3% ±50d Series
20.000mH 1µH 1.2% ±10d 1.2% ±50d Series
200.00mH 0.01mH 1.2% ±10d 1.2% ±50d Series
2000.0mH 0.1mH 1.5% ±15d 1.5% ±50d ---
20.000H 1mH 1.5% ±15d 1.5% ±50d Parallel
200.00H 0.01H 2.0% ±10d 2.0% ±50d Parallel
2000.0H 0.1H 2.5% ±15d 2.5% ±50d Parallel
continued ...
