Replacing The Fuses
WARNING: To avoid electric shock, disconnect the test leads from
any source of voltage before removing the meter cover.
1. Disconnect the test leads from the meter
2. Remove the protective rubber holster
3. Remove the battery cover (two “B” screws) and the battery
4. Remove the six “A” screws securing the rear cover
5. Gently remove the old fuse and install the new fuse into the holder
6. Always use a fuse of the proper size and value (0.5A/1000V fast blow
for the 400mA range [SIBA 70-172-40], 10A/1000V fast blow for the 20A
range [SIBA 50-199-06])
7. Replace and secure the rear cover, battery and battery cover
WARNING: To avoid electric shock, do not operate your meter until the
fuse cover is in place and fastened securely.
For service on this or any other REED product or information on other
REED products, contact REED Instruments at info@reedinstruments.com.
