General Maintenance
SERVICING THE ENGINE
See separate engine Owner’s Manual.
INSPECTING AND LUBRICATING THE MOWER
The reel bearings are sealed for life and do not require lubrication.
The following lubrication points should be oiled approximately every
25 hours of operation with SAE30-40 oil.
1. Driving Chains. Keep moistened with all purpose chain lubri-
cant. This lubrication requires the removal of the chain cover,
which can be lifted clear after unscrewing the three retaining
screws.
2. Ground speed lever pivot points.
3. Height Adjustment screw thread. Hand adjustment knob all
pivot points.
4. Cables. Apply oil to each end.
5. Self Adjusting Chain Adjuster. Apply oil to pivot.
Warning!
NEVER LUBRICATE WHILE MOTOR IS RUNNING.
Cleaning and storage
There is a direct relationship between the mower’s life and the care
and attention given to the mower both during and after operation.
It is important that the mower is thoroughly cleaned after use and
inspected so that it will be in good working order the next time it is
required.
Thoroughly clean the engine, under the chassis, the rollers and the
grass catcher. Use of a high pressure water jet, especially around
the engine, may force water into places where it may drive out lubri-
cants or cause hard starting from ignition damage.
LONG TERM STORAGE:
After each mowing season or if the mower is not going to be used
for 30 days or more, it is recommended that the fuel shut o valve
be closed o (where tted) and the fuel tank be drained as mod-
ern fuels have a short shelf life. The mower should then be started
up and run until all of the fuel left in the system is used. While the
engine is warm, drain the engine oil and rell with the correct grade
to the required level. Remove the spark plug and pour 5ml of engine
oil into the engine cylinder, crank slowly to distribute the oil and
replace the spark plug. Store the mower in a clean dry area away
from direct sunlight.
Adjust the cutting reel away from thebedknife and apply a thin layer
of grease to the cutting edges to prevent corrosion through the
storage period. If possible, spray the mower with a thin lm of light
oil to protect it.
Always store the mower on a at, level surface.
Specications
Model REV26-6
Weight 181 Lbs
Cut Width 26”
ENGINE INFORMATION
FOR DETAILED SPECIFICATIONS REFER SEPARATE
ENGINE OWNER’S MANUAL.
