8
(Reel Rollers Superstore – 2333 Peachtree Industrial Blvd, Buford, Georgia 30519 – www.reelrollers.com)
019116 R/MWR MAS 660 RRR H USA BLK- Jan 24
CUTTING REEL CLUTCH LEVER.
The reel lever is on the right of the upper handle. It engages the
cuttng reel. Move the lever to the forward positon (GREEN) to en-
gage, pull it back to (RED) positon to disengage.
RECOIL PULL START HANDLE
Refer to the engine owner’s handbook for details.
CLEAR THE AREA TO BE MOWN
Before commencing mowing, ensure the lawn is free from obstruc-
tions, such as stones, etc. Contact with objects of this type may
damage the cutting reel and bedknife.
Using your reel mower
STARTING THE ENGINE
Ensure the reel clutch bail is in the disengaged position before start-
ing the engine. Turn the ignition switch (if tted) to the ‘ON’ position.
Starting Procedure
If the engine has not been running recently move the choke control
to the ‘ON’/
position. The choke is on the side of the engine by
the carburettor, refer engine owner’s manual.
Stand to the right of the mower, grasp the starter grip, pull slowly
until a resistance is felt and then pull forcefully to prevent kick-back.
Repeat until the engine starts. Do not pull the cord with a jerk
or release it until fully rewound. When the engine starts and has
warmed up for a short time, move the choke to the ‘OFF’ position
and throttle control to the desired speed. Should the engine not
start due to ‘ooding’, move the Choke control to ‘OFF’ and pull the
starter six times to clear the ooding.
After allowing the engine to warm up, mowing may commence by
setting the throttle lever, so the engine is running suciently fast.
Engage the clutch lever, then engage the roller cutch by moving the
roller clutch lever forward towards the handle. Adjust the throttle to
achieve a comfortable walking pace and guide the machine in the
desired direction.
To Stop the machine, release the ground speed lever, disengage the
reel lever. Then reduce the engine speed.
To move the machine without mowing. With the engine running,
leave the clutch lever o and engage the roller clutch lever and
guide the machine in the desired direction.
HINTS FOR EASY STARTING.
1. Start a warm engine with the control in the SLOW position.
2. Keep the mower clean and the reel clear of debris.
HARD STARTING CHECK LIST
Look for these faults:-
FUEL.
1. Insucient fuel in tank.
2. Stale fuel.
3. Water or dirt in fuel.
4. Blocked air vent in fuel tank cap.
IGNITION.
1. Loose spark plug wire.
2. Dirty spark plug electrodes.
3. Incorrect spark plug gap.
4. Incorrect spark plug type.
OTHER.
1. Choked air lter (Dirt or oil).
2. Engine throttle control cable incorrectly adjusted.
3. Lower cutting blade incorrectly adjusted.
MOWING FLAT OPEN AREAS
When mowing at open areas it is best to rst cut a margin ap-
proximately widths at each end where you wish to turn the mower
and then mow at right angles to the margins with parallel cuts until
the area is completed. This leaves your lawn with a very pleasing
appearance. When turning at the end of each cut, disengage the
clutch and press down on the handles, turning the mower on its
rear roller. Once the throttle has been set to suit your pace, there
is no need for further adjustment unless you should encounter
very heavy grass growth. The mower can be controlled entirely by
means of the Roller clutch bail.
GROUND SPEED LEVER
When making tight turns, release the Ground Speed Lever to its
open position and re-engage the clutch when you want to resume
cutting.
When mowing around verges, the cutting reel and rear roller should
slightly overhang the bail edge ground speed lever.
