Reel Performance + - Operating Parameters

18 Performance + Electric Scooter User Manual
Operating Parameters.
OPERATING NAME REEL PERFORMANCE +
Dimensions
Length x Width x Height (cm) 109.5 x 42 x 114.5
Folded: Length x Width x Height (cm) 109.5 x 42 x 49.5
Weight Net weight (kg) 22
Conditions
Max load (kg) 120
Recommended user’s age 16+
Recommended user’s height (cm) 130 - 200
Main
Max speed km/h (mph) 25 (15.5)
Possibility in average condition (km) 35 - 40
Maximum slope (%) 17
Operating temperature range (˚C) 0 to 30
Temperature of storage (˚C) 0 to 30
Waterproof level IPX4
Battery
Rated voltage (VDC) 36V
Max voltage of charging (VDC) 42V
Smart battery
Management system
Stress, insufficient
voltage, short circuit,
auto sleep/wake up,
overheating protection,
control of battery usage.
Motor Rated power (W) 350
Power
Adaptor
Rated power (W) 85
Rate input voltage (VAC) 100-240V
Rated output voltage (VDC) 42V
Rated current (A) 1.5
Certificated CE, RoHS
Charging time (H) Est. 7 - 8h
