Reely GT2 EVO - Installing the Receiver

11
Attention!
If you still use a mechanical speed controller that has a BEC transmitter, it must not be used to supply the
receiver with power. The voltage pending at this plug is too high.
 Instead,useaseparatevoltagesourcewithfourbatteriesora4-to5-cellreceiverbattery.
Switch the transmitter on and then take the receiver into operation. If transmitter and receiver are bound correctly
(usuallysetexworks)theredcontrolLEDinthereceiverlightsup(seegure5,item16).Verifycorrectfunctionofthe
receiver and the connected servos and then switch it off again.
b) Installing the Receiver
Installationofthereceiverdependsonthemodel.Forthisreason,youshouldalwaysfollowtherecommendationsof
the model manufacturer regarding the installation.
Regardless of the model, you should always try to install the receiver so that it is protected from dust, dirt, moisture,
heatandvibrationinthebestpossibleway.Two-sidedadhesivefoam(servotape)orrubberringsthatholdthefoam-
wrapped receiver securely in place are suitable for fastening.
Attention!
The aerial wire (1) length is determined precisely.
 Forthisreason,youmustnotrollupthewire,placeit
in a loop or cut it off. This would decrease the range
signicantlyandthusposeaconsiderablesafetyrisk.
Route the aerial wire out of the mode through an
opening in the fuselage. Best use the aerial tube en-
closed with the remote control for this.
Figure 7
