CONTROL UNIT SERIES AUS X
8540643 - 26/08/2016 Rev.13 15
TECHNICAL DATA AUS X
Safety category
2
Power supply
Vdc
24  20%
Power requirement
W
5 max
Output
Relay
2 N.O. contacts (2A; 250V)
System Status Output
100mA; 24Vdc
Response time
ms
30 max
Operating modes
Manual or Automatic, selectable
from terminal block
External relay control
2 N.C. contacts (20mA; 24Vdc)
Number of
connectable photocells
1 ÷ 4
Connections
Terminal block with protection
against reversal of polarity
Status indicators
Led
Power On – Photocell Status – Fail
Max. length of connections
m
100
Operating temperature
°C
0 ÷ 55
Enclosure protection rating
IP 20
Terminal block protection
rating
IP 2X
Fastening
Fast attachment to rail according
to EN 50022-35
Dimensions (h x w x d)
mm
99 x 22,5 x 114,5
Weight
g
150
B10d
800.000
Device lifetime
20 years
Safety level
Type 2
EN 61496-1:2013
SILCL 1
IEC 62061(ed.1)
Cat.2
EN ISO 13849-1:2008
Load
Number of Commutations
PFHd *
DCavg
#
MTTFd
#
PL
#
CCF
#
2A@230Vac
1 every 30s
2,64E-08
98,92%
26,04
c
80%
1 every min
1,55E-08
98,85%
50,18
c
80%
1 every hour
4,98E-09
97,28%
100,00
c
80%
1 every day
4,82E-09
96,95%
100,00
c
80%
0,5A@24Vdc
1 every 30s
4,87E-08
98,96%
13,27
c
80%
1 every min
2,64E-08
98,92%
26,04
c
80%
1 every hour
5,16E-09
97,54%
100,00
c
80%
1 every day
4,83E-09
96,97%
100,00
c
80%
Table 4
* IEC 62061
#
ISO 13849-1
