PAGE 3
ENGLISH
INSTALLATION INSTRUCTIONS
3062400 • Questions? (800) 234-6992 • ReeseBrands.com
1
RAMP TOP INSTALLATION
1. After plank has been cut to proper length, insert plank into ramp
top and mark holes for drilling. FIG 1.
2. Remove ramp top and drill holes using 5/16" bit.
3. Bolt one ramp top to each plank, using hardware supplied in kit.
Carriage bolt with square shoulder under head will press into wood
to prevent turning. Orient bolts as shown in FIG 2.
2
Drill these holes in wood
Correct installation will
leave a gap. Do not force
wood under lip.
Carriage bolts
To Next Page
