Replacement parts and accessories
HSG-4065/4
Stop-Siphon Device, 4 pcs.
Part No 3004065
FUS-4050/10
Fuses 5x20 10A, 10 pcs.
Part No 3004050
PVC-TUBE
Plastic tube 6 mm (1⁄4”),
minimum 30 meters
Part No 4679160
FIL-4063/4
Filter, 4 pcs.
Part No 3004063
KIT-4087
Star tube with Stop-Siphon device
Part No 3004087
Conversion formula for
US Gallons/Hr:
_________ L/Hr. x 0.264 = _________ G/Hr.
A
B
C
A B C
Total Length (Run) Meters
Suction (lift) Discharge (Rise) m 5 10 15 20 30
0.0 m
0 42 42 40 40 40
1 (3.3ft.) 42 42 40 40 36
3 (9.9 ft.) 37 37 35 35 34
5 (16.4 ft.) 31 30 29 29 29
10 (32.8 ft.) 17 16 15 14 14
15 (49.2 ft.) 9 9 9 9 8
20 (65.6 ft.) 8 7
1.0 m (3.3 Ft)
0 42 42 42 40 40
1 (3.3ft.) 42 42 42 40 39
3 (9.9 ft.) 36 36 35 35 34
5 (16.4 ft.) 30 30 29 29 29
10 (32.8 ft.) 16 16 16 16 15
15 (49.2 ft.) 10 10 10 10 10
20 (65.6 ft.) 7 9
2.0 m (6.6 Ft.)
0 35 35 35 35 34
1 (3.3ft.) 33 33 33 32 31
3 (9.9 ft.) 33 32 31 31 30
5 (16.4 ft.) 27 26 26 26 25
10 (32.8 ft.) 17 17 16 16 15
15 (49.2 ft.) 10 10 10 9 9
20 (65.6 ft.) 5 5
3.0 m (9.9 Ft.)
0 30 30 30 30 29
1 (3.3ft.) 28 28 28 28 27
3 (9.9 ft.) 28 28 28 27 26
5 (16.4 ft.) 23 23 23 23 22
10 (32.8 ft.) 15 15 15 15 15
15 (49.2 ft.) 7 7 6 5 5
Corrected 󰈜 ow based on installation L/Hr. 1/4” (6mm) discharge tube @ full power
