12
Connect your headboard to the attachment plate using the
remaining long screws or hardware that came with your
headboard. The heads of the bolts will face outward. Use hex
key to tighten bolts.
headboard bracket installation guide (optional)
STEP 1
STEP 2
STEP 3
a.) Align the hole in the bracket to the brass sleeve into which
the leg threads. Hold the bracket in place and screw the leg
into the base until it is snug. DO NOT OVERTIGHTEN. Too
much force may cause the leg to spin freely.
b.) Align the tab with the hole in the frame (located towards
the foot of the base) and use a short bolt, washer and
wingnut to secure the bracket. Make sure the bolt is tight.
a.) Measure the distance between the mounting holes on the
headboard and install the T-Bracket to accommodate the
headboard.
Headboard Brackets are an optional accessory and are not included.
A hex key is included with the accessory kit to complete installation.
b.) To install the T-Bracket, slide the T-Bracket through the
end of the headboard bracket. Align the flat side of the
T-Bracket plate to the mounting holes on the headboard.
c.) Secure T-Bracket in place by inserting two short screws
through top of bracket. Use hex key to tighten screws.
