Reflexion Boost 2.0 - Quick Reference Guide

5
quick reference guide
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
Power Cord
Power Supply
Battery Backup
Box
Wireless
Remote
Head Motor
Foot Motor
Control Box
ELECTRONICS OVERVIEWCONTROL BOX OVERVIEW
Input
Power Cord
To remove Control Box,
release metal clip and
unplug cords.
If installing a split unit, see pages 10-11
Input Cord
Connection
Power LED
Light
Port Button Head
Motor Port
Foot Motor
Port
